电磁式蜂鸣器
| IMAGE . | PART NUMBER . | Φ | HEIGHT | LENGTH | WIDTH | MOUNTING TYPE | SPL [DB] | RATED VOLTAGE |
|---|---|---|---|---|---|---|---|---|
|
SMD-096050F-03040 有源 | / | 5 | 9.6 | 9.6 | SMD | 80 | 3.6 |
|
SMD-090032H-03627 | 9 | 3.2 | / | / | SMD | 85 | 3.6 |
|
SMD-090025H-03627 | 9 | 2.5 | / | / | SMD | 85 | 3.6 |
|
LW-16014-12023有源 | 16 | 14 | / | / | DIP | 85 | 12 |
|
LW-16014-05023有源 | 16 | 14 | / | / | DIP | 85 | 5 |
|
LW-12095-12023有源 | 12 | 9.5 | / | / | DIP | 85 | 12 |
|
LW-12095-09023有源 | 12 | 9.5 | / | / | DIP | 85 | 9 |
|
LW-12095-05023有源 | 12 | 9.5 | / | / | DIP | 85 | 5 |
|
LW-12095-03023有源 | 12 | 9.5 | / | / | DIP | 85 | 3 |
|
LW-09040C-05027R30 | 9 | 4 | / | / | DIP | 85 | 5 |
|
LW-09040C-03027R15 | 9 | 4 | / | / | DIP | 85 | 3 |
|
LW-12095-12024R110 | 12 | 9.5 | / | / | DIP | 90 | 12 |
|
LW-12095-05024R40 | 12 | 9.5 | / | / | DIP | 85 | 5 |
|
LW-12095-03024R32 | 12 | 9.5 | / | / | DIP | 85 | 3 |
|
LW-09055-05023有源 | 9 | 5.5 | / | / | DIP | 82 | 5 |
|
LW-09055-03023有源 | 9 | 5.5 | / | / | DIP | 82 | 3 |
|
LW-06036-05027R25 | 6.6 | 3.6 | / | / | DIP | 70 | 5 |
|
LW-06036-03027R16 | 6.6 | 3.6 | / | / | DIP | 70 | 3 |
|
LW-12085-01520R16 | 12 | 8.5 | / | / | DIP | 85 | 1.5 |
|
LW-12085-05020R42 | 12 | 8.5 | / | / | DIP | 85 | 5 |
